9.5T – 1-1/8" Screw Pin Bow Shackle (Blue Pin) | Able Forge SPB028
Heavy-duty forged alloy steel bow shackle with a 9.5-tonne WLL and screw pin for quick, secure connections. CE marked, quenched and tempered, hot-dip galvanised for lasting corrosion resistance.
- Working load limit
- 9,500 kg
- Material
- Forged alloy steel
- Safety factor
- 6
- Free UK delivery on orders over £180£150 ex VAT
- 30-day returns on stock items
-
2T 1/2" Blue Pin Dee Shackle – ABLE £5.20£4.33
-
3.25T 5/8" Blue Pin Dee Shackle £6.83£5.69
Questions? Call the team on 01638 731608, Monday to Friday, 9am to 5pm
Overview
The Able Forge SPB028 is a forged screw pin bow shackle rated to a 9.5-tonne Working Load Limit, permanently stamped on the body for instant, error-free identification on site. Built from quenched and tempered alloy steel, it delivers exceptional toughness, fatigue resistance, and uniform strength throughout, making it a dependable connection point for heavy-duty rigging, lifting, and lashing operations.
The wide bow profile comfortably accommodates webbing sling eyes, multi-leg chain configurations, and rope terminations. The screw pin design enables fast, tool-free installation and removal, while the distinctive blue pin provides immediate size and grade identification at a glance. The body is hot-dip galvanised for robust corrosion resistance in demanding environments.
CE marked and fatigue rated as standard. Shackles can be supplied proof-tested with third-party certificates (ABS, DNV, Lloyd's, or other) upon request at time of order.
- Working Load Limit: 9.5 t with a 6:1 safety factor (minimum breaking strength 6× WLL)
- Forged alloy steel construction, quenched and tempered for uniform strength and density
- WLL permanently stamped on body for quick, reliable identification
- Wide bow profile suits webbing slings, multi-leg chains, and rope terminations
- CE marked and fatigue rated; meets Federal Specification RR-C-271D Type IVA, Grade A, Class 2
- Optional proof-test certificates available from ABS, DNV, Lloyd's, or other bodies on request
Key features
- 0195-tonne WLL with 6:1 safety factor
- 02Forged alloy steel
- 03Wide bow profile
- 04Hot-dip galvanised body with blue screw pin
- 05CE marked & fatigue rated
Specification
