4.75T Forged Screw Pin Bow Shackle 3/4" – Blue Pin
Able forged alloy steel bow shackle with a 4.75t WLL and screw pin closure. CE marked, quenched and tempered, with WLL permanently embossed on the body for safe, reliable lifting and rigging.
- Working load limit
- 4.75 kg
- Min. breaking load
- 28,500 kg
- Material
- Forged alloy steel
- Safety factor
- 6
- Free UK delivery on orders over £180£150 ex VAT
- 30-day returns on stock items
-
2T 1/2" Blue Pin Dee Shackle – ABLE £5.20£4.33
-
3.25T 5/8" Blue Pin Dee Shackle £6.83£5.69
Questions? Call the team on 01638 731608, Monday to Friday, 9am to 5pm
Overview
This forged screw pin bow shackle from Able delivers a working load limit of 4.75 tonnes, making it a dependable connecting link for rigging, lifting, and load-securing applications across industrial, marine, and construction environments. The generous bow profile accommodates webbing sling eyes comfortably, allowing multi-leg arrangements and angular loading without distortion of the sling eye.
Each shackle is individually forged, not cast, ensuring a consistent grain structure throughout the body with no internal voids or air pockets. The shackle is quenched and tempered for optimum strength and toughness, and the working load limit is permanently embossed on the body for instant, on-site identification. The contrasting blue alloy pin makes it easy to distinguish from other grades at a glance.
- Forged alloy steel body, quenched and tempered for superior strength and toughness
- Working load limit permanently marked on every shackle body for quick on-site verification
- Bow profile ideal for use with webbing sling eyes and multiple-leg lifts
- Screw pin closure for secure, tool-free assembly and release
- CE marked; meets Federal Specification RR-C-271D Type IVA, Grade A; fatigue rated
Key features
- 01475t WLL forged alloy steel bow shackle
- 02Bow (anchor) profile suits webbing sling eyes and multi-leg lifting arrangements without distorting the sling
- 03Screw pin closure provides secure
- 04WLL permanently embossed on the body
- 05CE marked and fatigue rated
Specification
Delivery and returns
Next-day delivery to England, Wales and Scotland (excluding the Highlands) on stock orders placed before 2.45pm. Free delivery on orders over £180£150 ex VAT.
Stock items can be returned within 30 days. Made-to-measure items, including lifting chains, can only be returned if faulty or damaged in transit.
