3/4" Screw Pin Bow Shackle – WLL 6.5T
Able forged screw pin bow shackle with a 6.5-tonne working load limit in a 7/8" body size. Quenched and tempered, CE marked, and fatigue rated for reliable heavy-duty rigging.
- Working load limit
- 6,500 kg
- Min. breaking load
- 39,000 kg
- Material
- Forged steel, quenched and tempered
- Safety factor
- 6
- Free UK delivery on orders over £180£150 ex VAT
- 30-day returns on stock items
-
2T 1/2" Blue Pin Dee Shackle – ABLE £5.20£4.33
-
3.25T 5/8" Blue Pin Dee Shackle £6.83£5.69
Questions? Call the team on 01638 731608, Monday to Friday, 9am to 5pm
Overview
This forged screw pin bow shackle from Able delivers a 6.5-tonne working load limit (WLL) in a 7/8" nominal body size. The wide bow profile provides a broad bearing surface, making it ideal for use with webbing slings, round slings, and multi-leg chain assemblies. The WLL is permanently stamped directly onto the bow for instant on-site identification.
Manufactured from forged steel that has been quenched and tempered throughout, this shackle offers consistent grain density and superior structural integrity compared with cast alternatives. The alloy screw pin is matched to a CE-marked body, and the shackle is fatigue rated for demanding lifting and rigging applications. Minimum breaking strength is 6 times the working load limit.
- Working Load Limit: 6.5 tonnes (6,500 kg)
- Nominal size: 7/8" body
- Forged steel body, quenched and tempered
- WLL permanently stamped on the bow
- Fatigue rated; CE marked
- Meets Federal Specification RR-C-271D Type IVA, Grade A
- Minimum breaking strength 6× WLL
Key features
- 0165-tonne WLL permanently stamped on the bow
- 02Forged steel body
- 03Wide bow profile ideal for webbing slings
- 04CE marked and fatigue rated
- 05Screw pin design for secure
Specification
