12T 1-1/4" Screw Pin Bow Shackle – 12 Tonne WLL
Heavy-duty forged screw pin bow shackle with a 12-tonne Working Load Limit and 6:1 safety factor. CE marked, fatigue rated, and individually stamped for safe, reliable lifting and rigging.
- Working load limit
- 12,000 kg
- Min. breaking load
- 72,000 kg
- Material
- Forged steel, quenched and tempered
- Safety factor
- 6
- Free UK delivery on orders over £180£150 ex VAT
- 30-day returns on stock items
-
2T 1/2" Blue Pin Dee Shackle – ABLE £5.20£4.33
-
3.25T 5/8" Blue Pin Dee Shackle £6.83£5.69
Questions? Call the team on 01638 731608, Monday to Friday, 9am to 5pm
Overview
The Able Forge SPB032 is a heavy-duty forged screw pin bow shackle rated to a 12-tonne Working Load Limit, making it a dependable choice for demanding lifting, rigging, and marine applications. The wide bow profile accommodates webbing sling eyes, multi-leg chain slings, and other rigging components with ease, distributing load effectively across the connection point.
Every shackle is individually forged, then quenched and tempered for superior strength and toughness. The Working Load Limit is permanently stamped into the body for instant, on-site identification, eliminating any risk of misidentification in the field. A safety factor of 6:1 means the minimum breaking strength is 72 tonnes.
- Working Load Limit: 12 tonnes (12,000 kg)
- Safety factor 6:1, minimum breaking strength 6× WLL
- Forged steel body, quenched and tempered for consistent grain structure and density
- Screw pin closure with black pin for quick, secure fastening
- WLL permanently stamped on every shackle for easy identification
- CE marked
- Fatigue rated
- Can be proof tested and supplied with third-party certificates (ABS, DNV, Lloyd's) upon request
Suitable for use in lifting, crane rigging, shipping, construction, and general industrial applications.
Key features
- 0112-tonne WLL
- 02Forged & heat treated
- 03Bow profile
- 04Permanently stamped
- 05Certifiable on request
Specification
Delivery and returns
Next-day delivery to England, Wales and Scotland (excluding the Highlands) on stock orders placed before 2.45pm. Free delivery on orders over £180£150 ex VAT.
Stock items can be returned within 30 days. Made-to-measure items, including lifting chains, can only be returned if faulty or damaged in transit.
