8.5T Screw Pin Bow Shackle – 1" (6½T WLL)
A forged alloy steel CE-marked screw pin bow shackle with a 6½T working load limit, permanently stamped on the body. Ideal for rigging, lifting and load-securing in industrial, construction and marine environments.
- Working load limit
- 6,500 kg
- Min. breaking load
- 39,000 kg
- Material
- Forged alloy steel, quenched and tempered
- Safety factor
- 6
- Free UK delivery on orders over £180£150 ex VAT
- 30-day returns on stock items
-
2T 1/2" Blue Pin Dee Shackle – ABLE £5.20£4.33
-
3.25T 5/8" Blue Pin Dee Shackle £6.83£5.69
Questions? Call the team on 01638 731608, Monday to Friday, 9am to 5pm
Overview
This heavy-duty forged alloy steel screw pin bow shackle delivers a 6½-tonne working load limit (WLL) with a 6:1 safety factor, making it a reliable connecting link for demanding rigging, lifting and load-securing applications. The WLL is permanently stamped on every shackle body so there is never any doubt about the rating on site.
The generous bow profile readily accepts webbing sling eyes and multi-leg chain assemblies, while the hot-dip galvanised body provides excellent corrosion resistance. The contrasting black screw pin makes visual inspection quick and straightforward.
- WLL 6½T (6,500 kg) permanently stamped on the shackle body
- Forged alloy steel, quenched and tempered for superior strength and consistent grain structure
- 6:1 safety factor, minimum breaking strength is six times the working load limit
- CE marked and fatigue rated, suitable for repeated dynamic loading cycles
- Hot-dip galvanised body with black screw pin for corrosion resistance and easy inspection
- 1" nominal size (7/8 pin), compatible with standard rigging hardware
- Meets Federal Specification RR-C-271D Type IVA, Grade A performance requirements
Shackles can be supplied proof-tested with third-party certification (ABS, DNV, Lloyd's or equivalent) on request at the time of order. Quenched and tempered construction can meet DNV impact requirements of 42 joules at -20 °C upon request.
Key features
- 01WLL 6½T (6,500 kg) permanently stamped on every shackle body
- 02Forged alloy steel body
- 03CE marked and fatigue rated
- 04Hot-dip galvanised body
- 051" nominal size bow profile accepts webbing slings and multi-leg chain assemblies
