25T 1-3/4" Screw Pin Bow Shackle – WLL 25T
Heavy-duty forged alloy steel screw pin bow shackle with a 25-tonne working load limit. CE marked, fatigue rated, and hot-dip galvanised for lasting corrosion resistance in demanding lifting applications.
- Working load limit
- 25,000 kg
- Min. breaking load
- 150,000 kg
- Material
- Forged alloy steel
- Safety factor
- 6
- Free UK delivery on orders over £180£150 ex VAT
- 30-day returns on stock items
-
2T 1/2" Blue Pin Dee Shackle – ABLE £5.20£4.33
-
3.25T 5/8" Blue Pin Dee Shackle £6.83£5.69
Questions? Call the team on 01638 731608, Monday to Friday, 9am to 5pm
Overview
The Able Forge SPB044 is a heavy-duty forged screw pin bow shackle rated to a 25-tonne working load limit (WLL). Designed for demanding industrial, construction, and marine lifting applications, the wide bow profile accommodates webbing slings, allowing the sling eye to bear correctly without point loading.
Each shackle is individually forged from alloy steel, then quenched and tempered for consistent strength and toughness throughout. The WLL is permanently stamped on the body for fast, reliable identification on site. A 6:1 safety factor means the minimum breaking strength is 150 tonnes.
The hot-dip galvanised body provides excellent corrosion resistance, while the alloy screw pin ensures a secure, tool-free connection. CE marked and fatigue rated as standard; proof testing and third-party certification (ABS, DNV, Lloyd's) are available on request at the time of order.
- Forged alloy steel body, quenched and tempered for superior strength and toughness
- 25-tonne WLL permanently stamped on every shackle for on-site identification
- 6:1 safety factor (minimum breaking strength 150 tonnes)
- CE marked and fatigue rated as standard
- Hot-dip galvanised body for corrosion resistance; wide bow profile suitable for webbing slings and multi-leg applications
Key features
- 0125-tonne WLL permanently stamped on the body
- 02Forged alloy steel
- 036:1 safety factor
- 04CE marked and fatigue rated
- 05Hot-dip galvanised body with wide bow profile
Specification
