3/8" Bow Shackle – 1T WLL Screw Pin (SPB009)
Forged screw pin bow shackle with a 1-tonne Working Load Limit, CE marked and permanently stamped for confident identification. Ideal for rigging, lifting and load-securing with webbing slings, chains and wire ropes.
- Working load limit
- 1,000 kg
- Min. breaking load
- 6,000 kg
- Material
- Forged alloy steel, quenched and tempered
- Safety factor
- 6
- Free UK delivery on orders over £180£150 ex VAT
- 30-day returns on stock items
-
2T 1/2" Blue Pin Dee Shackle – ABLE £5.20£4.33
-
3.25T 5/8" Blue Pin Dee Shackle £6.83£5.69
Questions? Call the team on 01638 731608, Monday to Friday, 9am to 5pm
Overview
The Able SPB009 is a 3/8" forged screw pin bow shackle rated to a 1-tonne Working Load Limit (WLL), designed for rigging, lifting and general industrial load-securing applications. The wide bow (omega) profile comfortably accommodates sling eyes, master links and chain, distributing load evenly to reduce wear on your lifting accessories.
Forged from alloy steel and quenched and tempered for consistent grain structure and superior strength, this shackle eliminates the internal voids associated with cast alternatives. The WLL is permanently stamped on the body for fast, confident identification on site, and the shackle carries CE marking. The minimum breaking strength is 6 times the working load limit, in line with a 6:1 safety factor.
The screw pin closure provides secure, tool-free fastening and quick release when required. The hot-dip galvanised body offers corrosion resistance for use in demanding environments.
- Forged alloy steel body, quenched and tempered for uniform strength and reliability
- 1 tonne WLL permanently stamped on every shackle for instant on-site identification
- 6:1 safety factor, minimum breaking strength 6× WLL
- CE marked; meets Federal Specification RR-C-271D Type IVA, Grade A, Class 2 performance requirements
- Hot-dip galvanised body with screw pin closure for corrosion resistance and secure, tool-free fastening
Key features
- 01Forged & heat treated
- 021T working load limit
- 036:1 safety factor
- 04CE marked
- 05Screw pin bow design
Specification
