17T 1½" Screw Pin Bow Shackle – 17,000 kg WLL
Heavy-duty forged alloy steel screw pin bow shackle with a 17,000 kg (17 t) Working Load Limit. CE marked, fatigue rated, and hot-dip galvanised for lasting corrosion resistance in demanding lifting and rigging applications.
- Working load limit
- 17,000 kg
- Min. breaking load
- 102,000 kg
- Material
- Forged alloy steel
- Safety factor
- 6
- Free UK delivery on orders over £180£150 ex VAT
- 30-day returns on stock items
-
2T 1/2" Blue Pin Dee Shackle – ABLE £5.20£4.33
-
3.25T 5/8" Blue Pin Dee Shackle £6.83£5.69
Questions? Call the team on 01638 731608, Monday to Friday, 9am to 5pm
Overview
This heavy-duty forged screw pin bow shackle from Able delivers a 17,000 kg (17 t) Working Load Limit in a robust, fatigue-rated design suited to the most demanding lifting and rigging applications. The wide bow profile provides a generous bearing surface, making it ideal for use with webbing slings, multi-leg chain slings, and other rigging assemblies.
The shackle body is hot-dip galvanised for outstanding corrosion resistance, and the WLL is permanently stamped on the bow for instant, reliable identification on site. Quenched and tempered throughout, the shackle delivers consistent strength and toughness, and carries a 6:1 safety factor (minimum breaking load 102,000 kg) in line with standard rigging practice. CE marked and manufactured to Federal Specification RR-C-271D Type IVA, Grade A.
- Forged alloy steel body, quenched and tempered for uniform strength and toughness
- 17,000 kg (17 t) Working Load Limit with a 6:1 safety factor
- WLL permanently stamped on every shackle for easy on-site identification
- Hot-dip galvanised body for excellent corrosion protection
- Wide bow profile, optimised for webbing slings and multi-leg rigging assemblies
- Fatigue rated construction
- CE marked; meets Federal Specification RR-C-271D Type IVA, Grade A
Key features
- 0117,000 kg (17 t) Working Load Limit
- 02Forged alloy steel construction
- 03Hot-dip galvanised body
- 04Wide bow profile offers a broad bearing surface
- 05CE marked and fatigue rated
