13mm Sub Master Link Assembly – Grade 80 Alloy Steel (MLA-8-32)
Grade 80 alloy steel sub master link assembly for 3- or 4-leg chain slings. Designed for 13mm chain, with a WLL of 11.2 tonnes and proof tested to 2.5× WLL.
- Working load limit
- 11,200 kg
- Chain size
- 13 mm
- Grade
- Grade 80
- Material
- High-grade alloy steel, quenched and tempered
- Free UK delivery on orders over £180£150 ex VAT
- Returnable only if faulty or damaged in transit
-
2T 1/2" Blue Pin Dee Shackle – ABLE £5.20£4.33
-
3.25T 5/8" Blue Pin Dee Shackle £6.83£5.69
Every assembly is built to your spec, proof-tested and supplied with a certificate. Made-to-order items are not covered by next-day delivery. Need a non-standard length or fitting? Call 01638 731608.
Questions? Call the team on 01638 731608, Monday to Friday, 9am to 5pm
Overview
The 13mm Sub Master Link Assembly (Model MLA-8-32) is a heavy-duty, welded alloy steel master link assembly engineered for use with 3- or 4-leg Grade 80 alloy chain slings. The distinctive green powder-coat finish denotes Grade 80 status, and the assembly's unique tri-lobe design allows multiple sling legs to be attached securely to a single lifting point.
Manufactured from high-grade alloy steel (quenched and tempered), each assembly is individually proof tested to 2.5 times its Working Load Limit and carries a Product Identification Code (PIC) for full material traceability. The larger inside width and length dimensions make it fully compatible with wire rope thimbles as well as chain.
- High-grade alloy steel, quenched and tempered for maximum strength and durability
- Grade 80 rated, suitable for use with 13mm Grade 80 alloy chain on 3- or 4-leg sling configurations
- Individually proof tested to 2.5× WLL with certification supplied
- Product Identification Code (PIC) stamped for full material traceability
- Fatigue rated at 1.5× WLL with 20,000 cyclic test
Key features
- 01Grade 80 rated
- 02WLL 112 tonnes
- 03Traceable & marked
- 04High-grade alloy steel
- 05Fatigue tested
Specification
Delivery and returns
Next-day delivery to England, Wales and Scotland (excluding the Highlands) on stock orders placed before 2.45pm. Free delivery on orders over £180£150 ex VAT.
Stock items can be returned within 30 days. Made-to-measure items, including lifting chains, can only be returned if faulty or damaged in transit.
How to use lifting chains
A short guide from the team on using it safely and getting the most from it. Turn on captions with CC to follow along without sound.
