0.75T 5/16" Forged Bow Shackle – Screw Pin | 750 kg WLL
A CE-marked forged steel screw pin bow shackle with a 750 kg (0.75 t) working load limit. Quenched and tempered for consistent strength, with WLL permanently stamped on the body.
- Working load limit
- 750 kg
- Min. breaking load
- 4,500 kg
- Material
- Forged steel
- Safety factor
- 6
- Free UK delivery on orders over £180£150 ex VAT
- 30-day returns on stock items
-
2T 1/2" Blue Pin Dee Shackle – ABLE £5.20£4.33
-
3.25T 5/8" Blue Pin Dee Shackle £6.83£5.69
Questions? Call the team on 01638 731608, Monday to Friday, 9am to 5pm
Overview
A forged screw pin bow shackle rated to a 750 kg working load limit, suitable for connecting rigging components, lifting slings, and load-bearing assemblies across shipping, construction, and industrial applications. The wide bow profile provides ample room for webbing sling eyes and multi-leg sling connections.
The shackle body is forged steel, quenched and tempered, eliminating the air voids associated with cast components and ensuring consistent strength throughout. The working load limit is permanently stamped on every shackle for fast, reliable identification on site.
- 750 kg (0.75 t) working load limit, permanently stamped on body
- Forged steel body, quenched and tempered for consistent strength
- 6:1 safety factor (minimum breaking strength 6× WLL)
- Screw pin closure for secure, adjustable connection
- Bow (anchor) shackle profile, ideal for use with webbing slings
Key features
- 01750 kg (075 t) WLL permanently stamped on body
- 02Forged steel construction
- 036:1 safety factor
- 04Screw pin closure delivers a secure
- 05Bow (anchor) profile offers ample clearance
Specification
