10mm Connecting Link – Grade 80 Alloy Steel Chain Connector
A Grade 80 forged alloy steel connecting link for 10mm chain, rated to a 3,200 kg WLL. Enables quick, tool-free assembly and dismantling of lifting chain slings for overhead lifting applications.
- Working load limit
- 3,200 kg
- Min. breaking load
- 12,800 kg
- Chain size
- 10 mm
- Grade
- Grade 80
- Free UK delivery on orders over £180£150 ex VAT
- Returnable only if faulty or damaged in transit
-
2T 1/2" Blue Pin Dee Shackle – ABLE £5.20£4.33
-
3.25T 5/8" Blue Pin Dee Shackle £6.83£5.69
Every assembly is built to your spec, proof-tested and supplied with a certificate. Made-to-order items are not covered by next-day delivery. Need a non-standard length or fitting? Call 01638 731608.
Questions? Call the team on 01638 731608, Monday to Friday, 9am to 5pm
Overview
This Grade 80 alloy steel connecting link is designed to join sections of lifting chain or connect chain slings to lifting equipment, enabling safe and reliable overhead lifting across a wide range of industrial applications. Manufactured from high-grade alloy steel that has been drop-forged, quenched and tempered, the link offers exceptional strength and durability.
The simple two-body C-link design, secured by a pin and stud assembly, allows instant assembly, dismantling and reassembly without the need for specialist tools. Each link is individually marked with traceability information, WLL, batch number and size for easy identification and compliance record-keeping.
Suitable for use with Grade 80 alloy chain at 10mm diameter, this connecting link is an essential component for constructing and maintaining safe lifting chain slings in warehousing, construction, engineering and heavy industry.
- Manufactured from high-grade alloy steel, drop-forged, quenched and tempered for maximum strength
- Rated for Grade 80 alloy chain in lifting applications
- Tool-free assembly and dismantling via simple pin and stud design
- Individually marked with WLL, traceability, batch number and size
- 100% proof load tested at 2.5 times working load limit; ultimate load 4 times capacity
Key features
- 01Grade 80 rated
- 023,200 kg working load limit
- 03Tool-free assembly
- 04Fully proof tested
- 05Clearly marked
Specification
Delivery and returns
Next-day delivery to England, Wales and Scotland (excluding the Highlands) on stock orders placed before 2.45pm. Free delivery on orders over £180£150 ex VAT.
Stock items can be returned within 30 days. Made-to-measure items, including lifting chains, can only be returned if faulty or damaged in transit.
