Lifting chain failures are almost always preventable, and they nearly always trace back to one of a small number of root causes: overloading, wear, corrosion, fatigue, deformation or misuse. Understanding these failure modes, and knowing what to check for before every lift, is what keeps operators safe and keeps a certified Working Load Limit (WLL) valid between formal examinations. This guide explains the main causes of chain failure, how to spot the warning signs early, and what UK regulations require of anyone using lifting chains at work.
Failures rarely happen because of a single, dramatic event. Far more often, a chain that fails has been showing small warning signs for weeks or months before the incident, signs that were missed because no one was looking closely enough or because the chain was assumed to be fine simply because it had worked the last time it was used. Understanding what actually causes chains to fail changes that assumption from a guess into a checklist.
Why Lifting Chain Failures Happen
A lifting chain rarely fails without warning. In most cases, damage develops gradually through repeated use, poor storage or missed inspections, and the chain reaches a point where its actual capacity has dropped below its marked WLL long before anyone notices. Recognising the early stages of each failure mode is far more effective than waiting for a visible problem to appear.
Because several of these failure modes develop internally or below the surface, relying on appearance alone is not enough. A chain can look perfectly serviceable while carrying wear, fatigue cracking or elongation that has already reduced its safe capacity. This is why measured checks, not just visual ones, sit at the centre of any reliable inspection routine.
Common Failure Modes in Lifting Chains
Overloading
Exceeding the rated WLL is one of the most common causes of chain failure. Overloading stretches the links beyond their elastic limit, pushing the chain into plastic deformation. Once a link has stretched permanently, the chain's actual capacity is reduced even if it is later used within its original rated load. Matching the chain and assembly configuration to the actual load, including any dynamic or shock forces, prevents this from happening in the first place.
Wear
Wear occurs where links rub against each other or against hooks and connecting links during use. This thinning reduces the cross-sectional area of the metal, which lowers the load the link can safely carry. Wear is often difficult to see with the naked eye, particularly in the early stages, which is why measuring link diameter with a caliper rather than relying on a visual check is the only reliable way to catch it before it becomes dangerous. Chains used in abrasive environments, such as quarries or demolition sites, wear faster than those used indoors, and inspection frequency should reflect that.
Deformation
Bent, twisted or gouged links are a sign that a chain has been side-loaded, dropped, or caught on an obstruction during a lift. Deformation concentrates stress at the affected point, and a single deformed link can compromise the whole assembly regardless of how sound the rest of the chain appears. Any deformed link is a reason to withdraw the chain from service immediately.
Corrosion
Chains exposed to moisture, chemicals or salt air are vulnerable to corrosion, which can start as surface rust and progress to pitting that eats into the metal from within. Pitting corrosion is particularly dangerous because it can reduce a link's strength significantly before the damage is obvious from the outside.
Fatigue
Repeated loading, even within the rated WLL, causes microscopic cracks to form at the bearing contact points between links over time. Fatigue cracking is a gradual process and is one of the reasons chains used in continuous or high cycle applications need more frequent inspection than those used occasionally. Because fatigue damage begins beneath the surface, it can be present well before a crack becomes visible, which makes consistent inspection intervals more important than reacting only when something looks wrong.
Shock Loading
A sudden jolt, a dropped load, or an abrupt stop under tension applies forces far higher than the chain's static rating for a brief moment. Shock loading can cause elongation or internal damage without leaving an obvious external mark, which makes load history and incident records just as important as visual inspection.
Misuse
Using the wrong configuration for the load, knotting or twisting a chain to shorten it, or attaching it to unsuitable anchor points all place uneven stress on the assembly. Misuse is entirely preventable through correct training and by selecting the right chain and fittings for the job at hand. Operators who understand why a shortcut is risky, rather than simply being told not to take it, are far more likely to raise concerns before an unsafe lift takes place.
Inspection Tips for Catching Problems Early
A pre-use visual check before every lift is the first line of defence. Look along the full length for bent, twisted or cracked links, check hooks for throat opening and latch function, and confirm the identification tag is legible and matches the chain in use. Any doubt about a chain's condition is reason enough to remove it from service until it has been checked by a competent person.
Beyond the daily visual check, measured inspection matters. Link diameter should be checked with a caliper against the original certified dimension, and overall length compared to the figure recorded on the test certificate. These measurements catch wear and elongation long before either becomes visible to the eye. Our Advanced Lifting Chain Maintenance Guide covers the specific rejection thresholds used by competent persons in detail, including the wear and elongation limits set out in BS EN 818-4.
Maintenance Practices That Prevent Failure
Regular lubrication reduces friction at link-to-link bearing surfaces, which slows both wear and fatigue crack formation. Chains used outdoors or in wet conditions need more frequent lubrication than those kept in a dry indoor environment.
Correct storage also plays a major role. Assemblies left coiled on damp ground or exposed to chemical vapours corrode far faster than those hung on a dedicated rack in a dry, ventilated space. Keeping the identification tag with the chain at all times preserves traceability, since equipment without its tag has no verified WLL or examination history and cannot be treated as certified.
Training staff to recognise the early signs of wear, deformation and corrosion, and to report any doubt rather than continue using a questionable chain, closes the gap between formal examinations and prevents small issues from developing into failures.
UK Compliance for Lifting Chains
In the UK, lifting chains fall under the Lifting Operations and Lifting Equipment Regulations 1998 (LOLER), which requires thorough examination by a competent person at intervals not exceeding 6 months for general lifting use. The Provision and Use of Work Equipment Regulations 1998 (PUWER) also applies, requiring equipment to be maintained in an efficient state and stored in conditions that prevent deterioration.
Chains supplied in the UK are manufactured and tested to BS EN 818-4, which sets out the wear, elongation and deformation limits used to determine when a chain must be withdrawn from service. Compliance is not a one-off certificate at the point of purchase. It depends on maintaining the chain correctly between examinations and acting on any defect found during a pre-use check.
Frequently Asked Questions
What is the most common cause of lifting chain failure?
Overloading and undetected wear are the two most frequent causes, both of which reduce the chain's actual capacity below its marked WLL.
Can a worn chain be repaired?
No, chains with welded, reshaped or replaced links cannot be re-certified, since welding alters the metal's properties and invalidates the original certification.
How often must chains be inspected under UK law?
LOLER 1998 requires thorough examination by a competent person at least every 6 months, alongside a visual check before every use.
How can I tell if a chain has been shock loaded?
Shock loading often leaves no visible mark, so checking load history and withdrawing any chain involved in a dropped load or sudden arrest is the safest approach.
Does corrosion always look the same as wear?
No, corrosion often appears as pitting or surface rust, while wear shows as smooth thinning at contact points, and both require different checks to catch early.
Choosing and Maintaining Reliable Lifting Chains
Preventing chain failure comes down to understanding why chains fail, checking for the warning signs before every lift, and keeping up with lubrication, storage and formal examination requirements. The Ratchet Shop supplies lifting chains in single, two, three and four leg configurations, along with individual chain components such as master links and connecting links, all certified to BS EN 818-4 and supplied with full test documentation to support LOLER compliance.
