16mm Clevis C Hook
A Grade 8 alloy steel clevis C hook with a large open throat for fast, snag-free attachment and removal. Rated at 8,000 kg WLL, it is suitable for use with 16 mm lifting chain.
- Working load limit
- 8,000 kg
- Min. breaking load
- 32,000 kg
- Grade
- Grade 80
- Fittings
- C-hook
- Free UK delivery on orders over £180£150 ex VAT
- Returnable only if faulty or damaged in transit
-
2T 1/2" Blue Pin Dee Shackle – ABLE £5.20£4.33
-
3.25T 5/8" Blue Pin Dee Shackle £6.83£5.69
Every assembly is built to your spec, proof-tested and supplied with a certificate. Made-to-order items are not covered by next-day delivery. Need a non-standard length or fitting? Call 01638 731608.
Questions? Call the team on 01638 731608, Monday to Friday, 9am to 5pm
Overview
The clevis C hook offers a uniquely shaped large-throat opening that allows rapid hooking and unhooking without snagging, ideal for applications where a conventional safety-catch hook would slow operations down. Contoured body geometry prevents fouling on chain links, and the hook connects to chain via a robust clevis fitting with a cross-pin.
Manufactured to Grade 8 (80) standard from high-tensile alloy steel, each hook is individually marked with the manufacturer's identification and material grade for full traceability. The durable painted finish aids quick visual identification on site.
- Large open throat for fast, snag-free load attachment and release
- Contoured profile prevents fouling on chain links
- Grade 8 alloy steel construction, ultimate load is 4× the working load limit
- Clevis fitting with cross-pin for secure chain connection
- Fully traceable: manufacturer's ID and material grade marked on hook
- Suitable for 16 mm lifting chain; available in Green, Yellow or Orange painted finish
Browse the full range of Chain Components at The Ratchet Shop.
Key features
- 01Fast attachment
- 028,000 kg WLL
- 0316 mm chain compatible
- 04Fully traceable
- 05Durable finish
Specification
Delivery and returns
Next-day delivery to England, Wales and Scotland (excluding the Highlands) on stock orders placed before 2.45pm. Free delivery on orders over £180£150 ex VAT.
Stock items can be returned within 30 days. Made-to-measure items, including lifting chains, can only be returned if faulty or damaged in transit.
