1000kg Permanent Magnetic Lifter – ABLE PML-1000

ABLE PML-1000 Permanent Magnetic Lifter, 1000kg WLL

The ABLE PML-1000 Permanent Magnetic Lifter provides a powerful, reliable, and electricity-free solution for lifting and transporting ferromagnetic materials in workshops, fabrication yards, steel stockholders, and heavy engineering environments. With a working load limit of 1000kg, it eliminates the need for slings, chains, or clamps, protecting the surface finish of your workpieces and speeding up handling operations.

Operated by a simple rotary switch and safety button, the lifter can be engaged and released with one hand. Once activated, the permanent magnet circuit locks the load securely; when switched off, residual magnetism is less than 1%, ensuring safe and positive release every time.

Key Features

• 1000kg working load limit, suitable for heavy steel plates, moulds, and fabricated parts
• Permanent magnet operation, no electricity, no power cables, no risk of load drop due to power failure
• One-handed operation via simple switch and safety button
• Less than 1% residual magnetism on release for safe, controlled load release
• Eliminates slings and clamps, protecting workpiece surface finish
• Compact, robust cast body finished in green with black magnetic face
• Lifting capacity is dependent on material thickness and surface roughness (Ra ≤ 6.3 µm for full rated capacity)

Note: Lifting capacity is determined by the thickness and surface quality of the component. Where surface roughness (Ra) exceeds 6.3 µm, an appropriate derating should be applied. Always consult the capacity curve supplied with the unit before use.
