8000kg Heavy Duty Shackle Head Snatch Block
A heavy-duty steel snatch block with shackle head, rated to 8,000 kg (8 t) capacity. Fitted with a roller bearing sheave and opening gate for fast, easy wire rope insertion, ideal for lifting, pulling and redirecting applications.
- Working load limit
- 8,000 kg
- Rope diameter
- 20 mm
- Webbing width
- 160 mm
- Material
- Structural carbon steel
- Free UK delivery on orders over £180£150 ex VAT
- 30-day returns on stock items
-
2T 1/2" Blue Pin Dee Shackle – ABLE £5.20£4.33
-
3.25T 5/8" Blue Pin Dee Shackle £6.83£5.69
Questions? Call the team on 01638 731608, Monday to Friday, 9am to 5pm
Overview
This heavy-duty shackle head snatch block is built for demanding industrial lifting, pulling, towing and rope-redirect applications. Rated to an 8,000 kg (8 t) working load limit, it features a drop-forged wheel and roller bearing sheave for smooth, high-speed wire rope operation. The opening gate allows wire rope to be inserted quickly without the need to thread it through the block, saving valuable time on site.
The block is supplied in a robust blue painted finish and attaches via a galvanised shackle head (LS type). Structural carbon steel side plates and heat-treated alloy steel shackle components ensure reliable performance under sustained load.
Key Features
- Rated 8,000 kg (8 t) working load limit with a safety factor of 4 times
- Drop-forged steel wheel with roller bearing sheave for high-speed applications
- Opening gate design, insert wire rope without threading through the block
- LS-type shackle head attachment in galvanised steel
- Structural carbon steel side plates; heat-treated alloy steel shackle and pin
- Compatible wire rope size: 20-22 mm
- Suitable for lifting, pulling, towing and rope-redirect applications
Key features
- 018,000 kg (8 t) working load limit
- 02Drop-forged wheel
- 03Opening gate design
- 04Galvanised LS-type shackle head provides a secure
- 05Compatible with 20-22 mm wire rope
Specification
Delivery and returns
Next-day delivery to England, Wales and Scotland (excluding the Highlands) on stock orders placed before 2.45pm. Free delivery on orders over £180£150 ex VAT.
Stock items can be returned within 30 days. Made-to-measure items, including lifting chains, can only be returned if faulty or damaged in transit.
