Able HLC1 1-Tonne Horizontal Lifting Clamp (WLL 1T/Pair) – BS EN13155

Able HLC1 Horizontal Lifting Clamp, 1 Tonne WLL (Per Pair)

The Able HLC1 is a professional-grade horizontal lifting clamp engineered for the safe horizontal lifting and transfer of steel plates in construction, shipbuilding, and metal fabrication environments. Its specially thin ground plate and buffer cams allow easy insertion and removal beneath the plate being lifted, while the built-in pretension keeps the clamp securely attached even when unloaded.

This clamp can also be used hanging vertically under a spreader, making it highly versatile across a range of rigging configurations. It is equally suitable for turning steel beams from the H to the I position. All load-bearing parts are fully forged and heat treated, delivering the high strength and durability demanded in heavy industrial applications.

Key Features

• Designed for horizontal lifting and transfer of steel plates
• Thin ground plate and buffer cams for easy insertion and removal
• Built-in pretension keeps clamp on plate in unloaded position
• All parts fully forged and heat treated for maximum durability
• Embossed PI code for full traceability and quality assurance
• Minimum breaking load (MBL) of 500% of rated capacity
• Meets standard BS EN13155
• Suitable for surface hardness up to 37 RC (345 HB)

Working Fields

• Building and civil engineering construction sites
• Shipbuilding yards
• Metal production workshops
• Subway and underground construction projects

Please note: The WLL is given based on a pair of clamps. Always inspect prior to use as per the Able operating manual.
